Product Details ＋

TRB-BD73, 2 x NO, 3 Position Toggle Switch BLACK, Right ON, Centre = OFF, Left Biased, 3 Amp @ 240VAC, Plastic/Metal, IEC60947-5-1

Toggle Switches are used to Toggle between 2 or 3 Digital or Analogue Input Signals or to simply turn off control signals. Widely used for Rugged Industrial Applications Including Critical Machinery requiring safe and reliable repetitive operation by the user.

Features :

600V Insulation Rating
240VAC @ 3 Amp
22mm Cutout

Standards :

IP40
IEC60947-5-1
CE

Specification

TRENT Part Number	TRB-BD73-IP65
Functions	2 Pole, 3 Position Toggle Switch
Switch Type	Latching 1 x NO (Right ON Postion 1), Centre = OFF, 1 x NO (Left Biased Postion 2)
Nominal Voltage	240VAC @ 50/60Hz
Rated Impulse Voltage	6kV
Nominal Current Range AC	3 Amp @240VAC
Rated Insulation Voltage	600VAC
Humidity	35-85%
Approvals	CE
Standards	IEC60947-5-1, IP20 (IP40 Installed)
Weight	65g
Enclosure Material	UL94V0
Factory Pack Qty	1
TRENT(Fastron) Head Office	Australia
