Product Details
＋
TRB-BG45, Toggle KeySwitch 2 Pos Biased Black 1NO 1NC, IEC60947-5-1
Toggle Switches are used to Toggle between 2 or 3 Digital or Analogue Input Signals or to simply turn off control signals. Widely used for Rugged Industrial Applications Including Critical Machinery requiring safe and reliable repetitive operation by the user.
Features :
- 600V Insulation Rating
- 240VAC @ 3 Amp
- 22mm Cutout
Standards :
- IP40
- IEC60947-5-1
- CE
Specification
| TRENT Part Number | TRB-BG45 |
| Functions | 2 Pole, 3 Position Toggle Switch |
| Switch Type | Biased 1 x NO, 1 x NC |
| Nominal Voltage | 240VAC @ 50/60Hz |
| Rated Impulse Voltage | 6kV |
| Nominal Current Range AC | 3 Amp @240VAC |
| Rated Insulation Voltage | 600VAC |
| Humidity | 35-85% |
| Approvals | CE |
| Standards | IEC60947-5-1, IP20 (IP40 Installed) |
| Weight | 65g |
| Enclosure Material | UL94V0 |
| Factory Pack Qty | 1 |
| TRENT(Fastron) Head Office | Australia |
